General Specications
 Amplier Section
Rated Output Power (IEC)
7 ch × 135 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD
Maximum E󰀨ective Output Power (IEC)
7 ch × 160 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD
Dynamic Power (*)
* IEC60268-Short-term maximum output power
160 W (3 Ω, Front)
125 W (4 Ω, Front)
85 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz - 20,000 Hz, half power)
Input Sensitivity and Impedance
200 mV/47 kΩ (LINE (RCA))
Rated RCA Output Level and Impedance
1 V/470 Ω (SUBWOOFER PRE OUT)
1 V/2.3 kΩ (ZONE B PRE/LINE OUT)
Frequency Response
10 Hz - 100 kHz/+1 dB, –3 dB (Direct)
Tone Control Characteristics
±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio
109 dB (IHF-A, LINE IN, SP OUT)
Speaker Impedance
4 Ω - 16 Ω
Headphone Rated Output
80 mW + 80 mW (32 Ω, 1 kHz, 10% THD)
Supported impedance of Headphones
8 Ω - 600 Ω
Headphones Frequency Response
10 Hz - 100 kHz
 Tuner Section
FM Tuning Frequency Range
87.5 MHz - 108.0 MHz, RDS
50 dB quieting sensitivity (FM MONO)
1.0 μV, 11.2 dBf (IHF, 1 kHz, 100% MOD)
DAB Tuning Frequency Range
174.928 MHz - 239.200 MHz (Band III)
DAB Sensitivity
-100 dBm (Min.) (Band III)
Preset Channel
40
 BLUETOOTH Section
Communication system
BLUETOOTH Specication version 4.2
Frequency band
2.4 GHz band
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH proles
A2DP 1.3
AVRCP 1.5
HFP(Hands-Free Prole) 1.6
HSP(Headset Prole) 1.2
SPP(Serial Port Prole) 1.2
Supported Codecs
SBC
AAC
Transmission range (A2DP)
20 Hz - 20 kHz (Sampling frequency 44.1 kHz)
Maximum communication range
Line of sight approx. 15 m (*)
* The actual range will vary depending on factors such as obstacles between
