 5.1 Channel System (Bi-Amping the Speakers)
12
45
3
6
For high-
frequency
For low-
frequency
You can congure a 5.1 Channel System ( p16) by connecting front speakers that support Bi-Amping connection.
The Bi-Amping connection can improve the quality of the low and high pitched ranges. Be sure to remove the jumper bar
connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction
manual of your speakers as well.
 "Speaker Setup" settings during
Initial Setup ( p89)
Speaker Setup
Select how many speakers you have.
Next
ENTER
Speaker Channels 5.1 ch
Yes
Subwoofer
- - -Height Speaker
• Speaker Channels: 5.1 ch
• Subwoofer: Yes
• Height Speaker: ---
• Zone B Speaker: No
• Zone B Output Level: Variable
• Bi-Amp: Yes
• Speaker Impedance: Set any
value ( p22)
