Onkyo TX-SR502E - Page 73

20/41 PAGE
PCB
S7613 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7614 PUSH SW NPS-111-S681 1 25035718
PCB
S7614 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7615 PUSH SW NPS-111-S681 1 25035718
PCB
S7615 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7616 PUSH SW NPS-111-S681 1 25035718
PCB
S7616 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7617 PUSH SW NPS-111-S681 1 25035718
PCB
S7617 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7621 PUSH SW NPS-111-S681 1 25035718
PCB
S7621 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7622 PUSH SW NPS-111-S681 1 25035718
PCB
S7622 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7623 PUSH SW NPS-111-S681 1 25035718
PCB
S7623 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7624 PUSH SW NPS-111-S681 1 25035718
PCB
S7624 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7625 PUSH SW NPS-111-S681 1 25035718
PCB
S7625 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7627 PUSH SW NPS-111-S681 1 25035718
PCB
S7627 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7631 PUSH SW NPS-111-S681 1 25035718
PCB
S7631 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7632 PUSH SW NPS-111-S681 1 25035718
PCB
S7632 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7633 PUSH SW NPS-111-S681 1 25035718
PCB
S7633 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7634 PUSH SW NPS-111-S681 1 25035718
PCB
S7634 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7635 PUSH SW NPS-111-S681 1 25035718
PCB
S7635 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7636 PUSH SW NPS-111-S681 1 25035718
PCB
S7636 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7637 PUSH SW NPS-111-S681 1 25035718
PCB
S7637 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7638 PUSH SW NPS-111-S681 1 25035718
PCB
S7638 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7641 PUSH SW NPS-111-S681 1 25035718
PCB
S7641 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7642 PUSH SW NPS-111-S681 1 25035718
PCB
S7642 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7643 PUSH SW NPS-111-S681 1 25035718
PCB
S7643 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7644 PUSH SW NPS-111-S681 1 25035718
PCB
S7644 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7645 PUSH SW NPS-111-S681 1 25035718
PCB
S7645 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7646 PUSH SW NPS-111-S681 1 25035718
PCB
S7646 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7647 PUSH SW NPS-111-S681 1 25035718
PCB
S7647 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
JL7501A WIRE HOL NSCT-3P894 1 25051107
PCB
JL7501B WIRE HOL NSCT-3P894 1 25051107
PCB
JL7502A WIRE HOL NSCT-5P896 1 25051109
PCB
JL7502B WIRE HOL NSCT-5P896 1 25051109
U06 DRIVER AMPLIFIER PC BOARD (NAAF-8235-1A/1B/1D)
U07 COMPONENT VIDEO TERMINAL PC BOARD (NAVD-8236-1A/1B/1D)
U09 REGULATOR PC BOARD (NAETC-8238-1A/1B/1D)
U10 TERMINAL PC BOARD (NAETC-8239-1A/1B/1D)
U11 SPEAKER TERMINAL PC BOARD (NAETC-8240-1D)
U12 HOLDER PC BOARD (NAETC-8241-1A/1B/1D)
U14 TERMINAL PC BOARD (NAETC-8243-1A/1B/1D)
U15 SPEAKER TERMINAL PC BOARD (NAETC-8244-1A/1B/1D)
<Notes>
<Notes> Parts are indicated collectively, without dividing for above-mentioned each substrate.
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
