PCB
P5005 WS CLAMP CB-71683(L=50) 1 260261
PCB
P5800 TRM NTM-8PDMN304 1 25060373
<502 DD,DC>
PCB
P5800 TRM NTM-8PDMN305 1 25060374
<502 PA,WT,GK,GQ,GR,PT,>
PCB
P5800 TRM NTM-8PDMN305 1 25060374
<502E>,<8250>
PCB
P5802 TRM NTM-8PDMN306 1 25060375
<502 DD,DC>
PCB
P5802 TRM NTM-8PDMN307 1 25060376
<502 PA,WT,GK,GQ,GR,PT,>
PCB
P5802 TRM NTM-8PDMN307 1 25060376
<502E>,<8250>
PCB
P6000A SOCKET NSCT-5P2185 1 25052288
PCB
P6001A SOCKET NSCT-5P2185 1 25052288
PCB
P6002A SOCKET NSCT-5P2185 1 25052288
PCB
P6003A SOCKET NSCT-5P2185 1 25052288
PCB
P6004A SOCKET NSCT-5P2185 1 25052288
PCB
P6005A SOCKET NSCT-5P2185 1 25052288
PCB
P6011A SOCKET NSCT-10P2190 1 25052293
PCB
P6072 TRM NTM-1P233(M1969) 1 25060302
PCB
P6073 TRM NTM-1P233(M1969) 1 25060302
PCB
P6800 TRM NTM-4PDMN308 1 25060377
<520>
PCB
P6801 TRM NTM-4PDML309 1 25060378
<520>
PCB
P6802 TRM NTM-8PDMN306 1 25060375
<520>
PCB
P6931A SOCKET NSCT-16P1314 1 25051527
PCB
P7503B SOCKET NSCT-8P2138 1 25052241
PCB
P7503Bor SOCKET NSCT-8P1101 ( 1) 25051312
PCB
P7503Bor SOCKET NSCT-8P1841 ( 1) 25052054
PCB
P7503Bor SOCKET NSCT-8P1639 ( 1) 25051852
PCB
JL6803B SOCKET NSCT-6P98 1 25050270
<520>
PCB
JL6803C SOCKET NSCT-6P98 1 25050270
<502>,<502E>,<8250>
PCB
JL6804B SOCKET NSCT-6P98 1 25050270
<520>
PCB
JL6804C SOCKET NSCT-6P98 1 25050270
<502>,<502E>,<8250>
PCB
JL6805B SOCKET NSCT-4P96 1 25050268
<520>
PCB
JL6805C SOCKET NSCT-4P96 1 25050268
<502>,<502E>,<8250>
PCB
JL9501A WIRE HOL NSCT-7P898 1 25051111
PCB
JL9501B WIRE HOL NSCT-7P898 1 25051111
U16 POWER AMPLIFIER PC BOARD (NAAF-8245-1A/1C/1D/1E/1F/1H/1J/1K)
U17 POWER SWITCH PC BOARD (NASW-8246-1A/1C/1D/1E/1F/1H/1J/1K)
U18 TERMINAL SENSOR PC BOARD (NAPS-8247-1A/1C/1D/1E/1F/1H/1J/1K)
U19 POWER SUPPLY PC BOARD (NAPS-8248-1A/1C/1D/1E/1F/1H/1J/1K)
U20 TERMINAL PC BOARD (NAPS-8249-1A/1C/1D/1E/1F/1H/1J/1K)
U21 VIDEO PC BOARD (NAVD-8250-1A/1C/1D/1E/1F/1H/1J/1K)
U25 OUTLET TERMINAL PC BOARD (NAETC-8254-1A/1C/1D/1E/1F/1H/1J/1K)
U26 TERMINAL SENSOR PC BOARD (NAETC-8255-1A/1C/1D/1E/1F/1H/1J/1K)
<Notes>
REF. NO. NAME DESCRIPTION Q'TY PART NO
REMARKS
PCB
U281 PHT CP TORX179L 1 24120101
PCB
U282 PHT CP TORX179L 1 24120101
PCB
U283 PHT CP TORX179L 1 24120101
PCB
Q201 TR RN1241-A 1 2213631
PCB
Q201 or TR RN1241-B ( 1) 2213632
PCB
Q202 TR RN1241-A 1 2213631
PCB
Q202 or TR RN1241-B ( 1) 2213632
PCB
Q203 IC LA7956 1 22241759
PCB
Q204 TR KTA1267-GR 1 2215995
PCB
Q204 or TR 2SA933S-R ( 1) 2213354
PCB
Q205 TR KRA102M 1 2215770
PCB
Q205 or TR DTA114ES ( 1) 2213510
PCB
Q206 TR KRA102M 1 2215770
<Notes> Parts are indicated collectively, without dividing for above-mentioned each substrate.
<502>:TX-SR502 <DC> : Canadian model
<502E>:TX-SR502E(European model) <DD> : American model
<8250>:TX-SR8250(Chinese model) <GK> : Korean model
<520>:HT-R520(American model & Canadian model) <GQ> : Hong kong model
<GR> : Chinese model
<PA> : Australian model
<PT> : Asian model (230-240V)
<WT> : World wide model
To Next Page
