Onkyo TX-SR503E - Page 124

34/51 PAGE
PCB2
P7902 PIN JACK NPJ-6PDWWWRRR561 1 25045779
PCB2
P7902 or PIN JACK NPJ-6PDBL159 ( 1) 25045300
PCB2
P7904 PIN JACK NPJ-6PDWWWRRR561 1 25045779
PCB2
P7904 or PIN JACK NPJ-6PDBL159 ( 1) 25045300
PCB2
P7905 PIN JACK NPJ-6PDWLGREP562 1 25045780
PCB2
P7905 or PIN JACK NPJ-6PWRLGGP493 ( 1) 25045697
PCB2
P7907 PIN JACK NPJ-1PDP555 1 25045773
PCB2
P7907 or PIN JACK NPJ-1PDP510 ( 1) 25045720
PCB2
P9502 SOCKET 14PK-FJ 1 25053058
PCB2
E301A TRM NTM-1P232(M1700) 1 25060301
PCB2
J010 CRIMP AS CRIMP AS 1 2069925226UL
PCB2
J011 CRIMP AS CRIMP AS 1 2069925153UL
PCB2
JL5501 JMP LEAD JL12 300 B 1 2J300606B15
PCB2
JL891B SOCKET NSCT-5P97 1 25050269
PCB2
JL5501A WIRE HOL NSCT-12P883 1 25051096
PCB2
JL5501B WIRE HOL NSCT-12P883 1 25051096
PCB2
JL6006B SOCKET NSCT-5P97 1 25050269
PCB2
JL6200A WIRE HOL NSCT-5P896 1 25051109
PCB2
JL6200B SOCKET NSCT-5P97 1 25050269
PCB2
JL6402A WIRE HOL NSCT-3P874 1 25051087
PCB2
JL6402B WIRE HOL NSCT-3P874 1 25051087
PCB2
JL6600A WIRE HOL NSCT-7P898 1 25051111
PCB2
JL6603A WIRE HOL NSCT-9P900 1 25051113
PCB2
JL6952A WIRE HOL NSCT-5P896 1 25051109
PCB2
JL6952B WIRE HOL NSCT-5P896 1 25051109
U11 POWER SUPPLY-1 PC BOARD (NAPS-8533-1A/1B/1C/1D/1E/1F)
U12 OUTLET (MGK) PC BOARD (NAPS-8534-1E)
U13 POWER SUPPLY-2 PC BOARD (NAPS-8535-1A/1B/1C/1D/1E/1F)
U14 SEC. TERMINAL-1 PC BOARD (NAPS-8536-1A/1B/1C/1D/1E/1F)
U15 SPEAKER TERMINAL PC BOARD (NAETC-8537-1A/1B/1C/1D/1E/1F)
U16 CENTER SPEAKER TERMINAL PC BOARD (NAETC-8538-1A/1B/1C/1D/1E/1F)
U17 VIDEO PC BOARD (NAVD-8539-1A/1B/1C/1D/1E/1F)
U18 DRIVER AMPLIFIER PC BOARD (NAAF-8540-1A/1B/1C/1D/1E/1F)
CIRCUIT N
O
NAME DESCRIPTION Q'TY PART NO REMARKS
PCB3
Q930 IC SI-3010KF 1 22242203 <WT>
PCB3
Q1503 IC LA7956 1 22241759
PCB3
Q1512 IC LA7956 1 22241759
PCB3
Q1513 IC LA7956 1 22241759
PCB3
Q1519 IC NJM2585L 1 22242243
PCB3
Q921 TR 2SC2458-GR 1 2212115
PCB3
Q921 or TR 2SC2458-BL ( 1) 2212116
PCB3
Q921 or TR KTC3199-GR ( 1) 2215864
PCB3
Q1501 TR RN1241-A 1 2213631
PCB3
Q1501 or TR RN1241-B ( 1) 2213632
PCB3
Q1502 TR RN1241-A 1 2213631
PCB3
Q1502 or TR RN1241-B ( 1) 2213632
PCB3
Q1504 TR 2SA933S-R 1 2213354
PCB3
Q1504 or TR 2SA933S-S ( 1) 2213355
PCB3
Q1504 or TR KTA1267-GR ( 1) 2215995
