Onkyo TX-SR707 - Page 67

39/136 PAGE
AMP0072
R6312 NF CARBON R R25J-10 1 415471004T
AMP0072
R6313 NF CARBON R R25J-10 1 415471004T
AMP0072
R6314 NF CARBON R R25J-10 1 415471004T
AMP0072
R6315 NF CARBON R R25J-10 1 415471004T
AMP0072
R6316 NF CARBON R R25J-10 1 415471004T
AMP0072
R6701 C-CARBON R RN72K1J-223JE 1 435032234R1
AMP0072
R6702 C-CARBON R RN72K1J-103JE 1 435031034R1
AMP0072
R6704 C-CARBON R RN72K1J-473JE 1 435034734R1
AMP0072
R6706 C-CARBON R RN72K1J-224JE 1 435032244R1
AMP0072
R6708 C-CARBON R RN72K1J-333JE 1 435033334R1
AMP0072
R6709 C-CARBON R RN72K1J-392JE 1 435033924R1
AMP0072
R6710 C-CARBON R RN72K1J-123JE 1 435031234R1
AMP0072
R6712 C-CARBON R RN72K1J-103JE 1 435031034R1
AMP0072
R6714 C-CARBON R RN72K1J-333JE 1 435033334R1
AMP0072
R6716 C-CARBON R RN72K1J-563JE 1 435035634R1
AMP0072
R6902 C-CARBON R RN72K1J-102JE 1 435031024R1
AMP0072
R6903 C-CARBON R RN72K1J-473JE 1 435034734R1
AMP0072
R6907 C-CARBON R RN72K1J-000JE 1 435030004R1
AMP0072
RL6901 RELAY NRL-1P10A-DC12-140 1 25065584
!
TV-8
AMP0072
RL6902 RELAY NRL-1P10A-DC12-140 1 25065584
!
TV-8
U005 Speaker terminal PC board BATRM-0083-1A/1B
U006 Primary power supply PC board BAPS-0084-1A/1B
U007 Speaker terminal-2 PC board BATRM-0085-1A/1B
U008 Center speaker terminal PC board BATRM-0086-1A/1B
U009 Power amp. Input circuit PC board BACLA-0087-1A/1B
PCB
NO. PART NAME DESCRIPTION Q'TY PART NO. REMARKS
TRM0083-1B
C5000 UPZ C 2AUPZTF101JE 1 376331014T
TRM0083-1B
C5000 UPZ C 2AUPZTF101JE 1 376331014T
TRM0083-1B
C5001 UPZ C 2AUPZTF101JE 1 376331014T
TRM0083-1B
C5002 UPZ C 2AUPZTF101JE 1 376331014T
TRM0083-1B
C5003 UPZ C 2AUPZTF101JE 1 376331014T
