TECHNICAL SPECIFICATIONS
GRID
Nominal Voltage 220 V
ac
Voltage Tolerance 170 -264 V
ac
Frequency Tolerance 50/60 Hz ±%5
Internal Fuse 2 A
MOTOR
Type PMSM
Maximum Output Power 150 W
Nominal Current 0,7 A
rms
Output Frequency 0 – 120.0 Hz
Control Method Vector control
Short Circuit Protection Yes
ENCODER
Encoder Type 3 channels incremental
Encoder Resolution 100-2048 ppr
Encoder Voltage 5 V
dc
USER
INTERFACE
Language Options Turkish / English
Screen 2x16 Character LCD
Button 4 buttons
Warning Sound Buzzer
INPUTS
Open the door
Close the door
Programmable input 1 (Nudging / Photocell)
Programmable input 2 (Photocell / Nudging)
OUTPUTS
Fault relay (5A @ 250V
ac
or 30V
dc
)
Door opened relay (5A @ 250V
ac
or 30V
dc
)
Door closed relay (5A @ 250V
ac
or 30V
dc
)
ERROR TYPES
Press detected
Module error
Encoder V
CC
error
High V
dc
error
Low V
dc
error
Maximum door speed 80 cm/s
Operating Temperature -20 ~ +60 °C
EMC Approval EN 12015 / EN 12016
