4 - Power Management
4.1 - Wake-Up Events
The Helix platform supports multiple power states. The wake-up events can be configured in the
BIOS. This section describes the supported power management functions and gives information on
protection circuitry for power adapters. Low power shutdown is an additional option in the BIOS. See
Appendix C for more information.
Wake-Up Event
From ACPI State
Comments
Power Button
Low Power
shutdown, S5, S3
LAN
S5, S3
Must be enabled in BIOS
USB
S3
RTC Wake set by BIOS
S5
Must be enabled in BIOS
RTC Wake set by OS
S3
