Onlogic HX401 - M.2 M-Key

6.6.3 - M.2 M-Key
Pin
Function
Function
Pin
1
GND
3.3 V
2
3
GND
3.3 V
4
5
PERn3
NC
6
7
PERp3
NC
8
9
GND
NC
10
11
PETn3
3.3 V
12
13
PETp3
3.3 V
14
15
GND
3.3 V
16
17
PERn2
3.3 V
18
19
PERp2
NC
20
21
GND
NC
22
23
PETn2
NC
24
25
PETp2
NC
26
27
GND
NC
28
29
PERn1
NC
30
31
PERp1
NC
32
33
GND
NC
34
35
PETn1
NC
36
37
PETp1
NC
38
39
GND
NC
40
41
PERn0/SATA-B+
NC
42
43
PERp0/SATA-B-
NC
44
45
GND
NC
46
47
PETn0/SATA-A-
NC
48
49
PETp0/SATA-A+
PERST# (O)(0/3.3V) or NC
50
51
GND
CLKREQ# (I/O)(0/3.3V) or NC
52
53
REFCLKn
PEWAKE# (I/O)(0/3.3V) or NC
54
55
REFCLKp
NC
56
57
GND
NC
58
59
CONNECTOR Key M
CONNECTOR Key M
60
61
CONNECTOR Key M
CONNECTOR Key M
62
63
CONNECTOR Key M
CONNECTOR Key M
64
