6.2 - Appendix B: Isolated DIO guide
Additional information for the Isolated DIO can be found on the OnLogic support site. Please refer to
the link below for additional information.
ADP102 / ADP120 Isolated DIO module - OnLogic Support
6.3 - Appendix C: BIOS manual
For a detailed overview of the BIOS screens and individual settings, please refer to the OnLogic
support site. Instructions for updating the BIOS can also be found on the support site. Please refer to
the link below for detailed instructions.
https://static.onlogic.com/resources/manuals/OnLogic-HX401-BIOS-Manual-1.49-v1.pdf
6.4 - Appendix D: CAN user guide
Additional information for using the on-board CAN transceiver can be found on the OnLogic support
site. Please refer to the link below for additional information.
https://www.onlogic.com/support/documentation/hx400-technical-resources
6.5 - Appendix E: System thermal results
6.5.1 Test Conditions
● Temperature Range: 0ºC to 50°C
● Step size: 10°C
● i7 Processor, 1TB PCIe Gen3 x4 SSD, and 64GB RAM loaded @ 80% with BurnInTest 9.2
