5.4 - UKCA
The computer system was evaluated for medical, IT equipment, automotive, maritime and railway
EMC standards as a class A device. The computer complies with the relevant IT equipment directives
for the UKCA mark.
5.5 - VCCI
This is a Class A product based on the standard of the Voluntary Control Council for Interference
(VCCI). If this equipment is used in a domestic environment, radio interference may occur, in which
case the user may be required to take corrective actions.
6 - Appendices
6.1 - Appendix A: Power consumption
The power consumption of the HX4010 system was measured for various system configurations,
workloads, and power states at both 12V and 24V system input voltages. Tests were performed
using Burnintest v9.0 build 1012 to stress system components with and without graphics enabled.
The build configurations and power consumption are listed in the tables below.
*The configurations below are using representative samples of internal devices, the specific
components mentioned below may vary from the devices provided by OnLogic. The power
consumption for each system configuration is record below
System
Component
Config 1 Ultra- Low
HX401
Config 2 Low
HX401
Config 3 Medium
HX401
Config 4 High
HX401
CPU
Celeron 7305E
5 Core: 1P+4E &
48EU
i3-1220PE
8 Core: 4P+4E &
48EU
i5-1250PE
12 Core: 4P+8E &
80EU
i7-1270PE
12 Core: 4P+8E &
96EU
Memory
8GB DDR5
So-DIMM
1x TS1GSA64V8G
Transcend
16GB DDR5
So-DIMM
1x TS2GSA64V8E
Transcend
32GB DDR5
So-DIMM
1x TS4GSA64V8E
Transcend
64GB DDR5
So-DIMM
2x TS4GSA64V8E
Transcend
LAN
1x Intel I219
1x Intel I219
1x Intel I219
1x Intel I210
1x Intel I219
1x Intel I210
