1.3 - Product Specifications
OnLogic HX400 Series
Processor
Intel 12th Gen Alder Lake-P
Celeron, Core i3, i5, i7 up to 12-core (8P+4E) 16-thread
Memory
2x DD5-4800 SO-DIMM up to 64GB total (non-ECC)
Integrated Graphics
Intel® UHD Graphics for 12th Gen Intel® Processors (7305E, i3-1220PE)
Intel® Iris® Xe (i5-1250PE, i7-1270PE)
Front I/O
1x Power Button (LED Backlit)
4x USB 3.2 Gen 2
2x Type C USB 4 (40 Gb/s)*
3FF-Sim slot (Mapped to the B-Key)
1x DIO port Punch out
*Thunderbolt Certification Pending
Back I/O
2x Full size DisplayPort 1.4a
2x Gb LAN
Terminal Block Option - Punch out
2x Antenna punch outs
1x Serial/CAN Punch out
Barrel Jack with 19~24 V input
Expansion & Storage
1x M.2 2280/60/3042 B-Key (PCIe Gen 3 x1, USB 3.0, SATA III)
1x M.2 2230 E-key (Wi-Fi) (PCIe x1/ USB 2.0)
1x M.2 2280 M-key (PCIe Gen 4 x 4, SATA III)
Onboard Headers &
Connectors
1x Battery on a cable
1x Serial Header, RS 232/422/485
2x USB 2.0 (1x4 header)
16 Pin input for Terminal Block Power
Special Features
Watchdog timer
RTC
Onboard TPM - Infineon SLB9672
BIOS option for auto power-on
Optional Add On
Module
4G, CAN Bus, COM (RS-232/422/485), DIO (x4/x4), Terminal Block
Operating Systems
Windows 11 Pro 64 Bit*
Windows 10 IoT Enterprise 2021 LSC Value (Celeron/i3/i5) / High End (i7)
Ubuntu 22.04 Desktop / Server IOT
*Limited support - Refer to support.onlogic.com/documentation/onlogic-and-intel-collaboration/
LAN controller
1x Intel I219 and 1x Intel I210
Voltage Input
rated input: 19~24V via DC jack or 12~24V via Terminal Block, +/- 10% tolerance
