20 21
The equipment uses an onboard charging system integrated within the wiring harness which charges bat-
tery during normal use.
The battery can be recharged oine with any o-the-shelf battery charger with the following specs:
Voltage = 12 volts
Charging Amperage = 0.5 to 15 Amps
Battery Specs:
Model
Volltage (V)
Capacity (Ah)
Weight
Charging Current
Charging Voltage
Cold Cranking Amps
Cycle Life
HJTZ5S-30-GFP
12.8
3
0.7 kg / 1.5 lb
0.5A to 15A
14.4 0.5 V
180
≥1000
BATTERY MAINTENANCE
Battery Charging Procedures:
1. Disconnect the plastic battery cable terminal on equipment, and remove battery from equipment.
2. Connect the charger clamps to the battery posts:
• Red clamp on the positive “+” post
• Black clamp on the negative “-” (ground) post
3. If the charger has settings, set the output voltage and amperage within the ranges noted above.
4. Plug in the battery charger to standard wall outlet in a well ventilated area.
5. For best results, leave the charger connected for minimum of 8 hours.
6. Disconnect battery from charger by reversing steps 5-2
7. Reinstall battery on equipment, and connect the plastic battery cable terminal.
Take the following steps when storing the machine:
1. Ensure the ignition switch is turned to “o”.
2. Remove the propane tank, and store in an approved outside location.
3. Disconnect battery cable connectors, to prevent battery drain. When disconnected, the battery will keep
its charge in storage
for approximately 12 months.
4. Store machine in an indoor, climate controlled location with low humidity.
If equipped with a dust collection system, the dust bag should be serviced frequently as follows:
Note: The bag will remain functional for approximately 20-30 cycles, after which the bag should be replaced.
1. Stop engine.
2. Remove the bag from the dust chute, but pulling the elbow out of the dust chute.
3. Unzip the back of the bag.
4. Empty the contents of the bag into a garbage receptacle and shake out any debris. This is best done out-
side.
5. Reinstall the bag onto the dust chute, and secure the bag to machine via the rope loop and velcro on bag.
1. Stop the engine.
2. Adjust handle position to highest position and rock machine back, until handle grips are resting on
ground.
3. Remove the Pad Holder by turning it counterclockwise.
4. Remove the Pad, by pealing it o of the gripper surface
5. Install a new Pad onto the gripper surface, paying attention to keep it centered and aligned with the grip-
per surface.
6. Reinstall the Pad Holder, and tighten it by turning it clockwise.
DUST COLLECTION MAINTENANCE
HOW TO CHANGE PAD
WARNING: Whenever working on a machine in the rocked back position, ask an assistant to
hold the handle and prevent the machine from falling forward.
STORAGE
