Opel Blazer - Electrical System Components

Fuses and Circuit Breakers
The fuse block is on the driver’s side of the instrument
panel. You can remove the fuses with a fuse extractor.
Look at the silver-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical size
and rating.
Fuse/Circuit Breaker ................................Usage
A ................................................... Power Door Locks
B ...................................................... Power Windows
1 ........................................ Stoplamp, Hazard Flasher
Fuse/Circuit Breaker ................................Usage
2 ........................... Horn, Power Mirror, Interior Lamp
3 .............................. Parking Lamp, Underhood Lamp
4 .............................................. Cluster, Transmission,
Rear Wiper, Alarm Module
5 ...................................................... Injectors 2 and 4
6 ......................... Heater/Ventilation/Air Conditioning
Control Module
7 ............................................Auxiliary Power Outlets
8 ............................................................. Rear Defog
9 ............................................. Rear Wheel Anti-Lock,
Engine Control Module, Fuel Pump Relay
10 ............................. Ignition, Engine Control Module
11 ..................................................... Injectors 1 and 3
12 ............................................................ Cooling Fan
13 .................................................................... Radio
14 ................................................ Tail/Parking Lamps
16 ....................... Turn Signal Lamps, Back-Up Lamps
17 .................................................. Windshield Wiper
18 .................................. Vehicle Speed Sensor Buffer,
Rear Wheel Anti-Lock Module
21 .............................................................. Fog Lamps
22 ................................... Redundant Fuel Pump Relay
23 ..................................................................... Radio
24 ......................................... Electronic Spark Timing
