86 Overview
Sure Sort™ Operator Manual
OPEX Corporation
3.1. System Overview
Please take time to familiarize yourself with the various parts of the machine,
which are referred to throughout this manual.
Figure 3-1: Main Components
Operator Station
iBOT loading area
Delivery bins
Reject bin enclosure
iBOT
Light Tower
Optional OPEX
Optional
Scan Tunnel
Host Computer/UPS
Optional Stop Light Feature
(per column)
Light Tower
Return
Conveyor
