98 Overview
Sure Sort™ Operator Manual
OPEX Corporation
3.4.4. Module Dimensions
Note: Weights marked with an asterisk (*) include a maximum of 350 lbs per
column per side, or 50 lbs of product per bin at 7 bins per column per side if
anchored to the floor. Otherwise, the maximum per-column weight is 100 lbs.
Pack-to-light (PTL)
Customizable LED indicators (example, bin full
or order complete)
Expansion Modules Up to 11
Module
Width Length
Foot-
print
Height
Std.
Weight
Installed
Weight
Weight /
Sq. Ft.
Induct
24” 82” 13.7 ft² 71” 714 lbs 714 lbs 33 lb/ft²
Base
34.5” 58.5” 14.0 ft² 89” 668 lbs 1160 lbs* 83 lb/ft²
Expansion
57” 44.5” 17.6 ft² 89” 220 lbs 2058 lbs* 117 lb/ft²
Return
conveyor
25.5” 68.5” 12.2 ft² 46” 215 lbs 215 lbs 17.8 lb/ft²
Scan tunnel
39.5” 39.5” 10.8 ft² 60” 161 lbs 161 lbs 14.9 lb/ft²
