Optek TF16 - Standard Window; Gaskets (Not Wetted); Screw Sets

Maintenance
- 29 -
optek-Manual--1004-2006-02--TF16-US-2011-06-20
www.optek.com
9.5.2 Standard window
** others on request
Observe that for TF16 sensor and its variants only type A windows may be in-
stalled on the detector side!
9.5.3 Gaskets (not wetted)
9.5.4 Screw sets
Tab. 15 Spare parts — standard window
Sensor type / name Name / type Old part number New part number
standard window**
(see corresponding arma-
ture manual)
Pyrex
®
type A 0410-0050-01
type B 0410-0051-01
type C 0410-0052-01
type K 0410-0053-01
Saphire type A 0410-0050-03
type B 0410-0051-03
type C 0410-0052-03
type K 0410-0053-03
type AM 0410-0056-03
type BM 0410-0057-03
type CM 0410-0058-03
Tab. 16 Spare parts — gaskets
Gaskets (4 of each)
Viton
®
Old part number
Viton
®
New part number
10.10 x 1.60 0208-4004-02 1203-0004-0008-02
21.95 x 1.78 0208-4001-02 1203-0004-0015-02
25.12 x 1.78 0208-4002-02 1203-0004-0016-02
31.47 x 1.78 0208-4003-02 1203-0004-0018-02
50.52 x 1.78 1203-0004-0021-02
Tab. 17 Spare parts — screw sets
(10 of each) Old part number New part number
M3 x 6 (DIN 7985) 0101-1001-03 1206-0010-0023-03
M3 x 12 (DIN 7985)
incl. washer M3 (DIN 7980)
0101-1002-03 1206-0010-0077-01
