Programming
General Information:
• Your security system was designed with a great deal
of concern for you to feel comfortable with the
programming and maintenance of your security
system.
• has attempted to include all of the necessary
information into this documentation in an easy to use
format.
• We highly recommend that if there are areas in the
programming of the alarm system that you may not
fully understand, please ask for assistance with a
qualified technician until you have a complete
understanding of all the options available to you and
their functions.
Operation:
1. Press PROGRAM.
2. Enter your PIN (the default PIN = 1234).
• The top line of the keypad display will change to
“User Program” and the bottom line will be scrolling
your programming options listed below:
1. PIN Program
2. Set Clock
3. Schedules
4. Extend Close
5. Duress
6. Auto Monitor
7. Holiday
(Please note that each option has a number assigned).
1. PINs
General Information:
• Personnel Identification Numbers (PINs) are access
codes that will allow you and/or your employees to
control your security system.
• Each user should have his or her own PIN and these
individual PINs should not be shared with co-workers.
• The reason for individual PINs is each time a
command is initiated that requires the entry of a PIN,
the command will be logged into the memory buffer
by the user number assigned to the PIN along with a
time/date stamp.
• You may enter any four number digit that you wish for
any user.
• User number one PIN level cannot be changed and
must remain a level one.
(continued)
Programming (continued)
1. PINs
General Information:
• As a safety feature the keypad will automatically
remove itself from the programming mode after
approximately 60 seconds of inactivity realized by the
control panel. You will have to re-enter the program
mode so it is therefore recommended that you have a
list of the levels and PINs before you initiate the PIN
program.
• Deleting PINs is accomplished in the same manner as
entering PINs with the exception of you must press
RESET and then ENTER when the PIN is on the
keypad display.
• See PIN level chart on page 13.
Operation:
1. Press number one (1) button (PIN program).
2. Press SCAN repeatedly until the desired PIN is on the display.
3. Enter level + PIN (new PIN will pulsate).
4. Press ENTER.
5. Press SCAN to next PIN - Repeat steps 4 - 6
or
1. enter your PIN (level 1 only).
2. Press PROGRAM.
3. Press 1 (PIN Program menu).
4. Press PROGRAM.
5. Keypad will display “Set User Number”.
6. Select user number 01 - 99.
7. Press ENTER.
8. Press CLEAR.
9. Enter level + PIN (new PIN will pulsate).
10. Press ENTER.
11. Press CLEAR to return to USER PROGRAM.
2. Time / Date
Description:
• The time clock is an integral part of your alarm system
due to the fact that many of the options available in
your security system are timing functions.
• On occasion there may be a need to re-enter the
time/date. A complete loss of power (AC and your
standby battery) would necessitate that the time and
date to be re-entered and the keypad would the
message “Set Clock”.
• Notify your alarm company immediately should you
need to re-enter the time and date.
• Time The keypad display be requesting that you enter
the time that you require in standard time (not military
time). Enter the time and then press 0 for AM or 1 for
PM.
• Date The keypad display will be requesting that you
enter the date.
(continued on next page)
