Assembly Instructions
A. Attach the Front Stabilizer(1) and Rear Stabilizer(2) to the Backrest Support(3), Align the
hole and secure each of them with one M10*82MM Hex Bolt(21)，two Φ10mm Washers (29)
and one M10 Aircraft Nut(28).
B. Select Desired incline and lock the Front Stabilizer (1) and Rear Stabilizer (2) to the Backrest
Support (3), to the Backrest Support (3) with two 95MM Lock Pins (11).
Step 1
