OPTi 616/2629 - Step 3: Pad Attachment

7
Assembly Instructions
A. Attach the Seat Pad (9) to the two Seat Pad Supports (5&6), Align the hole and secure with
four M8*42MM Hex Bolts (25) and four Φ8MM Washers (30).
B. Attach the Backrest Pad (10) to the Backrest Pad Support(3), Align the hole and secure with
four M8*16MM Hex Bolts (26) and four Φ8MM Washers (30).
Step 3
