Opticon ESL Server User Manual

Opticon ESL
ESL Server manual
v1.0.62.2
7
1.4. Environmental Specifications
1.4.1. Operating Temperature and Humidity (EE201)
Temperature: 5 to 50° C
Humidity: 20-85%
1.4.2. Storage Temperature and Humidity (EE201)
Temperature: -20 to 60° C
Humidity: 20-85%
1.5. Interface Specifications
The radio interface of both the base stations and ESLs have the following specifications:
 2.4gHz IEEE 802.15.4 compatible
 Transmission speeds: up to 250 kbps
1.6. Electrical Specifications
1.6.1. Electrical Characteristics
EE201:
Parameter
Typical
Unit
Remarks
Operating voltage
2.8–3.2
V
2 x CR2450 Lithium battery
Operating current
7-33
mA
During RF and image refresh only
Sleep current
1
uA
EE201 is in sleep state >99,9%
EBS-30 / EBS-40:
Parameter
Typical
Unit
Remarks
Operating voltage
6.0
V
Power adapter
Operating current
<300
mA
