Service Manual
Manufactured by Bersch & Fratscher GmbH
3
version 10/2008
OPTIMA 2100
1. Intended use
Pneumatically operated paint spray gun with pump support in the high pressure range (up to
max. 250 bar) for processing liquid, sprayable media with consideration of the manufacturer
references. The high pressure spray gun is led by hand and operated by the operator to coat
the work piece.
2. Safety references
2.1. Safety references for the operator
a) Read all safety references and instructions. Failure to adhere to the safety references and
instructions can lead to danger and/or cause serious injuries.
b) Save all safety references and instructions for the future and keep them at the operating
place available, so that they can be seen by the operator as well as the personnel.
c) Make sure that all local guidelines for the industrial safety and rules for the prevention
of accidents are followed at any time.
2.1.1 Qualification of the personnel
The equipment may only be set up, operated and repaired by qualified and trained
personnel.
2.1.2 Security of the working environment
a) Ensure that the work area is always kept clean and well lit. Clutter or dim work areas can
lead to accidents.
b) Ensure that the floor of the work area is antistatic, in accordance with EN50053 part of 1,
§ 7-2, measurement according to DIN 51953 and that all persons within the work area
wear antistatic shoes, e.g. shoes with leather soles.
c) Ensure that the operators wear antistatic gloves for grounding over the handle of the
spray gun when painting.
d) Obey all local regulations concerning the overspray exhaustion and make sure that they
exist at the operating place and that they are used properly.
e) In addition the following components of a safe working environment must exist and/or be
available:
- Make sure that for the high operating pressure there are appropriate material
and air hoses available and used.
- Make sure that the personnel has personal protection equipment available and
uses it. Using personal protection equipment, such as breath and skin
protection, as well as if necessary. skid-proof safety shoos, reduce the risk of
injuries.
f) Guarantee that no ignition sources such as open fire, spark, glowing wires
or hot surfaces are present in the work area and that there is no smoked in the
work area.
2.2 Safety refereces for the operators
Read the operating instructions completely and in detail before start-up of the spray gun. All
information in this manual is to be followed particularly the general safety references and the
warning references.
Local guidelines for industrial safety and rules for the prevention of accidents
are to be followed at all times.
