OPTIMUM 600M // 5
ASSEMBLY INSTRUCTION
6.
Install the assembled Auger and strainer into
the juicing bowl upright; connect the Auger
axle with the motor rotating shaft.
8.
Place the pusher into the feeding hole, then
position the juice cup and pulp cup below the
juice outlet and pulp outlet.
7.
Install the hopper assy on the juicing bowl. Use
the mark points found on the drum cap and the
cup to properly align both pieces, then rotate
the drum cap clockwise until secure.
