Optimum 600M - ASSEMBLY INSTRUCTION; Step-by-Step Assembly Guide (Part 1)

4 // OPTIMUM 600M
ASSEMBLY INSTRUCTION
1.
Open the product package, take out the
product and accessories, and dispose of the
packing material.
2.
Clean the product surface and wash the
accessories with water. Do not wash the main
body.
5.
Insert the silicone brush into the auger base,
then install the auger into the juice auger.
3.
Before assembling the juicing bowl on the main body, make sure the pulp stopper and Shaft seal on
the bottom is inserted properly. If the pulp stopper and shaft seal is not inserted properly, the sealing
will not be eective, and juice will spill outside of the device.
4.
Put the juicing bowl on the main body and use
align the mark points on both pieces. When
the mark points are aligned, rotate the bowl
clockwise. See Figure for example.
REVERSE THE STEPS CAREFULLY WHEN DISASSEMBLING.
SHAFT SEAL
PULP STOPPER
