Optoma EH501 - Rear View; Bottom View

EN-8
Rear View
Bottom View
Ceiling mount holes
Rear adjustment feet
Note
 This projector can be used with a ceiling mount for support. The ceiling mount is not
included in the package.
 Contact your dealer for information to mount the projector on a ceiling.
Optional air dust Rear IR remote control sensor
AC power socket Optional wireless dongle slot
Connection ports Speaker
Kensington lock Ventilation holes
1
3
8
2
4
5 6
7
1 5
2 6
3 7
4
8
2
1
1
2
2
