EN-80
AMX Device Discovery commands
UDP : 239.255.250.250
Port No. : 9131
Each UDP broadcast information as below are updated around 40 seconds
Attention
1. This AMX function is only to support AMX Device Discovery.
2. The broadcast information only send out through valid interface.
3. Both LAN and Wireless LAN interfaces could be supported at the same
time.
4. If "Beacon Validator" was used. Please take care below information.
Command Description Value
Device-UUID
MAC address(Hex value without ‘:’
separator)
12 digits
Device-
SDKClass
The Duet DeviceSdk class name VideoProjector
Device-Make Maker name MakerPXLW
Device-Model Model name Projector
Config-URL
Device’s IP address
LAN IP address is shown up if LAN IP
address is valid.
Wireless LAN IP address is shown up if
Wireless LAN IP address is valid.
http://xxx.xxx.xxx.xxx/index.html
Revision
The revision must follow a
major.minor.micro scheme.
The revision is only increased if the
command protocol is modified.
1.0.0
