Optoma EP771 - Carton

Rev. 03
Company Confidential Optoma_______________________ Delta____________
71
2007/02/08
Board 12
MAIN BOARD ASSEMBLY (205mm x 141mm x
1.45mm FR-4)
DP-3622 XXXXX 5600600252 1
Ballast 13
LAMP DRIVER
(OSRAM LAMP DRIVER 200W PULSE 4AC03)
DP-3622 XXXXX 0990076200 1
Optical 14 0.7"XGA OPTICAL MODULE DP-3622 DP-3622 XXXXX 3797604700 1
Lamp
module
15
LAMP HOUSING ASSEMBLY FOR SPARE PARTS
DP-3622
DP-3622 XXXXX 3797610800-SO 1
Carton 16 CARTON PAPER 416*386*294 DP-3622 XXXXX 3517129701 1
Speaker 17
SPEAKER ASSEMBLY
(8 0hm 3W 290mm Wire, 51mm*40.6mm*25mm)
DP-3622 XXXXX 3791001806 1
Keypad 18
KEYPAD BOARD ASSEMBLY
(112mm x 65mm x 1.2mm FR-4 )
DP-3622 XXXXX 5600600271 1
TYPE NO Accessories P/N Q'ty
Cable 19
CABLE SIGNAL USB USB L2000 IVORY (USB
CABLE 2m)
DP-3622 XXXXX 3080337300 1
Cable 20
CABLE SIGNAL D-SUB D-SUB L2000 BLK (RGB
CABLE 2m)
DP-3622 XXXXX 3080425001 1
Cable 21
CABLE SIGNAL RCA RCA L1800 YEL
(Composite video RCA x1 to RCA x1) (1.8m)
DP-3622 XXXXX 3080301101 1
26 AC POWER CORD 3P #18*3C L3000 BLK
3622 JOTCG/
JOTCH/ JOTZG
3072050701
28 AC POWER CORD 3P 3G*0.75mm^2 L3000 BLK U
DP-3622 JOTEG
/JOTHG
3090211102
27 AC POWER CORD 3P 3G*0.75mm^2 L3000 BLK E
DP-3622 JOTDE
/ JOTDG
3090211200
29 AC POWER CORD 3P 3G*1.0mm^2 L3000 BLK C
DP-3622 JOTFG
3090123801
Cable
30 AC POWER CORD 3P 3G*1.0mm^2 L3000 BLK AU DP-3622 JOTIG 3090211300
1
CD 22 CD SOFTWARE PACKING ASSY (CD Disc)
DP-3622 JOTDG
3534017302 1
Manual 23
MANUAL QUICK START GUIDE TROUBLE
SHOOTING
DP-3622 XXXXX
5010054300 1
Case 24 CARRYING CASE PP 330*290*110 DP-3622 XXXXX 3523018900 1
DP-3622 JOTCG
/JOTCH
5041814400
Remote 25
REMOTE CONTROLLER 27KEYS
(27KEY LASER MEDIA IR REMOTE CONTROL UNIT)
DP-3622 JOTEG
/JOTDG/ JOTDE
/ JOTFG/ JOTHG
/ JOTIG/ JOTZG
5041814200
1
