HD25/HD25LV/HD25e
Item Description Parts
Supply
1 ASSY BOTTOM COVER MODULE HD25LV
2 SPEAKER 8FB 8W 8-OHM WITHOUT TUBING HD25LV V
3 ASSY MAIN BOARD MODULE HD25
4 ASSY TOP COVER AND ZOOM RING MODULE EH1020
5 FOCUS RING BLACK HD200X (FOR YM40)(LGSM)
ASSY LAMP COVER BLACK FOR EX615 (SERVICE) V
6 LAMP COVER BLACK EX615(LGSM)
7 LOCK SCREW PAN MECH M3*8.5-3.5 BLACK(1018+HEAT
TREATMENT)
ASSY PHILIPS E20.9 240W LAMP MODULE HD25LV V
LAMP MODULE FOR PROJECTOR HD25e V
8 ASSY PHILIPS E20.9 240W LAMP MODULE HD25LV
9 SCREW PAN MECH M3*5 Ni
10 TOP COVER SHIELDING HD20s
11 SCREW DOUBLE FLAT MECH M2*3Ni
12 PAN SCREW M3*8 FOR YM-64 FRONT CELL & SP
13 SCREW PAN MECH M2.6*6 Ni NYLOK
14 ASSY 8525 FAN SHIELDING MODULE HD25LV
15 SCREW PAN MECH M3*6 NI
