HD25/HD25LV/HD25e
Item Description Parts Supply
ASSY OPTICAL ENGINE MODULE FOR 8RV(SERVICE) V
ASSY OPTICAL ENGINE MODULE FOR 8VC(SERVICE) V
1 ASSY ENGINE BASE MODULE H15 ADD BOSS HD25LV
ASSY ROD MODULE FOR HD20 (SERVICE) V
ASSY ROD MODULE FOR 8RU(SERVICE) V
2 ASSY ROD MODULE HD20
3 ASSY RELAY MODULE EW762
ASSY COLOR WHEEL MODULE FOR 8RV (SERVICE) V
ASSY COLOR WHEEL MODULE FOR 8PJ (SERVICE) V
4 ASSY COLOR WHEEL MODULE HD25
5 ASSY ENGINE BOTTOM HD20
6 Projection Lens TR1.5 - 1.8 (YM40Y)
7 DMD HEATSINK AL6063 H15
8
S450 0.55” XGA/SVGA DMD thermal pad, FUJIPOLY, Sarcon
XR-HE, 18.4x12.5x0.5 mm
9 SPRING FOR DMD STEP SCREW X1161
10 STEP SCREW FOR DMD M2.6*16.2mm X1161
11 SPRING FOR DMD STEP SCREW X116
12
DMD 1920*1080 PIXEL 0.65” 1080P 2xLVDS DC3 S600 1910-
6037E
V
13
CNNT F 350P 0.55” 1080P S600 BGA DMD ZIF SOCKET
EPZ350;FOXCONN
14 HEX SCREW M2.6*H8*L4,BRASS
15 CONDENSER LIGHT STOP SUS304 0.3t 1609WX
16 KINKO CONDENSER 1 FOR A15W
17 KINKO CONDENSER 2 FOR A15W
18 DMD INSULATION PC A15
19 DMD PLATE AL A6061 M409WX
20 ROD COVER WXGA HYBRID K750
21 ROD SPRING SUS301 HD20
22 DMD ANTIDUST RUBBER 739 SILICONE RUBBER
23 PCBA DMD BOARD FOR HD21 PROJECTOR V
24 SCREW PAN MECH M2.6*6 Ni NYLOK
25 DMD HEATSINK SPRING SUS304 M409WX
26 DMD SHOULDER SCREW SB21
27 SCREW PAN TAP M1.7*4 BLACK
28 GASKET W*10 H*10 L*40
29 EMI GASKET W13*H6*L35
