HD25/HD25LV/HD25e
Assy Bottom Cover Module
5
6
7
1
2
4
3
8
Item Description Parts Supply
1 8HW BOTTOM COVER WHITE LN2520 LGSM
V
2 ADJUST FOOT P1266
3 YH-NUT-M2.0*2.0*4.0
4 8EG BOTTOM SHIELDING T=0.6MM
5 SECURITY BAR EX525ST
6 SECURITY BAR CAP PC LN2520 WHITE HD20
7 SCREW PAN TAP M3*5 Ni
8 EMI GASKET W5*H1.0*L155mm PD527
