Optoma HD25e - Page 60

Condential 11
HD25/HD25LV/HD25e
Assy Main Board Module
1
2
3
4
5
6
Item Description Parts Supply
1 PCBA MAIN BOARD FOR HD25 PROJECTOR V
2 MAIN BOARD SHIELDING HD25LV
ASSY IO COVER MODULE FOR 8RV WHITE(SERVICE) V
3 IO COVER WHITE HD25LV (LGSM)
4 SCREW PAN TAP M3*6 Ni
5 SCREW HEX I/O #4-40 H4*L8 NI NYLOK
6 SCREW PAN MECH M3*5 Ni
