ADDITIONAL INFORMATION
Projector dimensions and ceiling mount installation
 1/4-20 UNC thread (screw hole for tripod)
157
25
75
75
122
50 60
35
17.5
Unit: mm
Lens
Note: Please note that damage resulting from incorrect installation will void the warranty.
Warning:
 Be sure to keep at least 10 cm gap between the ceiling and the bottom of the projector.
 Avoid installing the projector near a heat source.
