Installation
 This graph is for user’s reference only.
Adjusting the Projector’s Zoom / Focus
You may turn the zoom ring to zoom in or out. To focus the
image, rotate the focus ring until the image is clear.

1.1x Zoom series will focus at distances from 4.92 to 32.81
feet (1.50 to 10.00 meters).
Adjusting Projection Image Size
Hd
57.7"
(146.4cm)
138.4"
(351.5cm)
184.5"
(468.6cm)
230.6"
(585.8cm)
276.7"
(702.9cm)
38.1"
(96.6cm)
63.4"
(161.1cm)
152.2"
(386.6cm)
202.9"
(515.5cm)
253.7"
(644.3cm)
304.4"
(773.2cm)
34.6"
(87.9cm)
4.92'
(1.50m)
39.37'(12.00m)
32.81'(10.00m)
26.25'(8.00m)
19.69'(6.00m)
8.20'(2.50m)
Width
Height
Diagonal
Screen
(Diagonal)
Max.
38.1” (96.6cm) 63.4” (161.1cm) 152.2” (386.6cm)202.9” (515.5cm) 253.7” (644.3cm) 304.4” (773.2cm)
Min.
34.6” (87.9cm) 57.7” (146.4cm) 138.4” (351.5cm)184.5” (468.6cm) 230.6” (585.8cm) 276.7” (702.9cm)
Screen
Size
Max.
(WxH)
30.4” x 22.8”
77.3 x 58.0cm
50.7” x 38.1”
128.9 x 96.6cm
121.8” x 91.3”
309.3 x 232.0cm
162.4” x 121.8”
412.4 x 309.3cm
202.9” x 152.2”
515.5 x 386.6cm
243.5” x 182.6”
618.6 x 463.9cm
Min.
(WxH)
27.7” x 20.8”
70.3 x 52.7cm
46.1” x 34.6”
117.2 x 87.9cm
110.7” x 83.0”
281.2 x 210.9cm
147.6” x 110.7”
374.9 x 281.2cm
184.5” x 138.4”
468.6 x 351.5cm
221.4” x 166.0”
562.3 x 421.7cm
Hd
Max.
3.42” (8.70cm) 5.71” (14.50cm) 13.70” (34.79cm)18.26” (46.39cm) 22.83” (57.99cm) 27.40” (69.59cm)
Min.
3.11” (7.91cm) 5.19” (13.18cm) 12.45” (31.36cm)16.60” (42.17cm) 20.76” (52.72cm) 24.91” (63.26cm)
Distance
4.92’ (1.50m) 8.20 (2.50m) 19.69’ (6.00m) 26.25’ (8.00m) 32.81’ (10.00m) 39.37’ (12.00m)
POWER
?
Focus Ring
Zoom Ring
