English
4
SAFETY
The lightning ash with arrow head within an equilateral triangle is
intended to alert the user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may be of sufcient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
Please follow all warnings, precautions and maintenance as recommended in this user's guide.
Important Safety Instruction
To prolong the effective life of the lamp, make sure to keep the lamp on for at least 60 seconds and
avoid performing force shutdown.
RG2
Do not stare into the beam, RG2.
As with any bright source, do not stare into the direct beam, RG2 IEC 62471-5:2015.
Do not block any ventilation openings. To ensure reliable operation of the projector and to protect from
over heating, it is recommended to install the projector in a location that does not block ventilation.
As an example, do not place the projector on a crowded coffee table, sofa, bed, etc. Do not put the
projector in an enclosure such as a book case or a cabinet that restricts air ow.
To reduce the risk of re and/or electric shock, do not expose the projector to rain or moisture. Do not
install near heat sources such as radiators, heaters, stoves or any other apparatus such as ampliers
that emits heat.
Do not let objects or liquids enter the projector. They may touch dangerous voltage points and short
out parts that could result in re or electric shock.
Do not use under the following conditions:
± In extremely hot, cold or humid environments.
(i) Ensure that the ambient room temperature is within 5°C ~ 40°C
(ii) Relative humidity is 10% ~ 85%
± In areas susceptible to excessive dust and dirt.
± Near any appliance generating a strong magnetic eld.
± In direct sunlight.
Do not use the projector in places where ammable gases or explosives gases may be present in the
atmosphere. The lamp inside the projector becomes very hot during operation and the gases may
ignite and result in a re.
Do not use the unit if it has been physically damaged or abused. Physical damage/abuse would be
(but not limited to):
± Unit has been dropped.
± Power supply cord or plug has been damaged.
± Liquid has been spilled on to the projector.
± Projector has been exposed to rain or moisture.
± Something has fallen in the projector or something is loose inside.
Do not place the projector on an unstable surface. The projector may fall over resulting in injury or the
projector may become damaged.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Optoma UHD51 and is the answer not in the manual?

Optoma UHD51 Specifications

General IconGeneral
Native aspect ratio16:9
Projection distance1.2 - 8.1 m
Vertical scan range24 - 120 Hz
Horizontal scan range31 - 135 kHz
Projection technologyDLP
Supported aspect ratios4:3, 16:9
Contrast ratio (dynamic)500000:1
Contrast ratio (typical)-
Screen size compatibility34.1 - 302.4 \
Projector native resolution2160p (3840x2160)
Lamp power240 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source4000 h
Service life of light source (economic mode)10000 h
Offset105 %
Throw ratio1.21 - 1.59:1
Zoom capabilityYes
Focal length range12.81 - 16.74 mm
Vertical lens shift range-10 - 10 %
DVI portNo
HDMI connector typeFull-size
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in0
Noise level25 dB
On Screen Display (OSD) languagesCHI (SIMPL), DEU, ENG, ESP, FRE, ITA, JPN, POR, RUS
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Supported graphics resolutions640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 2160
PlacementDesktop
Product typeStandard throw projector
Product colorBlack
Market positioningHome cinema
Cable lock slot typeKensington
Cables includedAC
RMS rated power10 W
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)305 W
Power consumption (standby)0.5 W
Operating altitude0 - 3000 m
Operating temperature (T-T)5 - 40 °C
Operating relative humidity (H-H)10 - 85 %
Weight and Dimensions IconWeight and Dimensions
Depth281 mm
Width392 mm
Height118 mm
Weight5220 g
