1.5 Model overview
The cameras of the PI series are available in the following basic versions:
Model
Model code
Temperature range
Spectral range
Frame rate
Typical applications
PI 160
IR
-20 to 900 °C
200 to 1500 °C (optional)
7.5 - 13 µm
120 Hz
Surface measurements in industrial application
PI 200/ PI 230
BI-SPECTRAL
-20 to 900 °C
200 to 1500 °C (optional)
7.5 - 13 µm
128 Hz
Synchronous recording of VIS and IR videos and images
PI 400i/ PI 450i
IR
-20 to 900 °C
200 to 1500 °C (optional)
7.5 - 13 µm
80 Hz
Real-time thermographic images in high speed;
Detection of smallest temperature differences (PI 450i)
PI 450i G7
IR
200 to 1500 °C
150 to 900 °C
7.9 µm
80 Hz/ 27 Hz
Measurement of glass (with Line-Scanning mode)
PI 640
IR
-20 to 900 °C
200 to 1500 °C (optional)
7.5 - 13 µm
32 Hz
Pin-sharp radiometric recordings in real time
PI 640 G7
IR
200 to 1500 °C
150 to 900 °C
7.9 µm
32 Hz
Measurement of glass (with Line-Scanning mode)
PI 05M
IR
900 to 2450 °C
500 – 540 nm
Up to 1 kHz
Measurement of metallic surfaces, graphite or ceramics
with short wavelengths
PI 08M
IR
575 …1900 °C
780 – 820 nm
Bis 1 kHz
Measurement of metallic surfaces, graphite or ceramics
with short wavelengths, especially for laser applications
PI 1M
IR
450 to 1800 °C
0.85 - 1.1 µm
Up to 1 kHz
Measurement of metallic surfaces, graphite or ceramics
with short wavelengths
Table 1: Model overview
