optris PI 200 User Manual

Technical Data 15-
2.2 Electrical specifications
Power Supply:
5 VDC (powered via USB 2.0 interface)
Current draw:
Max 500 mA
AO: Output Standard Process Interface
(PIF out)
0 - 10 V (Main measure area, measure area, internal temperature, flag status, recording status, line scan status,
alarm, frame sync, fail-safe, external communication)
[►Appendix F – Wiring diagrams PIF]
AI: Input Standard Process Interface
(PIF in)
0 - 10 V (Emissivity, ambient temperature, reference temperature, uncommitted value, flag control, triggered
snapshots, triggered recording, triggered linescanner, triggered event grabber, reset peak-/value-hold, switch
temperature range)
[►Appendix F – Wiring diagrams PIF]
DI: Digital Input Standard Process
Interface
Flag control, , triggered snapshots, triggered recording, triggered linescanner, triggered event grabber,
reset peak-/value-hold, switch temperature range
[►Appendix F – Wiring diagrams PIF]
Digital interface:
USB 2.0
