optris PI 200 User Manual

-24 -
■
HFOV: Horizontal enlargement of the total measuring at object level
■
VFOV: Vertical enlargement of the total measuring at object level
■
IFOV: Size at the single pixel at object level
■
DFOV: Diagonal dimension of the total measuring field at object level
■
MFOV: Recommended, smallest measured object size of 3 x 3 pixel
The following tables with examples showing what spot sizes and pixel sizes will be
reached in which distance. For individual configuration there are different lenses
available. Wide angle lenses have a radial distortion due to their large opening angle;
the software PIX Connect has an algorithm which corrects this distortion. As an
alternative to the tables below, the optics calculator can also be used on the optris
website (https://www.optris.global/optics-calculator) or via the optris calculator app. The
app can be downloaded for free from the Google Play Store (see QR Code).
