optris PI 200 User Manual

-58 -
The process interface has an integrated fail-safe mode. This allows to control conditions like interruption of
cables, shut-down of the software etc. and to give out these conditions as an alarm. The time constant of the
fail-safe is 1.5 seconds.
Controlled conditions on camera and software
Standard Process interface
ACPIPIF
Industrial Process interface
ACPIPIFMACBxx
Interruption USB cable to camera


Interruption data cable camera - PIF


Interruption power supply PIF


Shut-down of PIX Connect software


Crash of PIX Connect software
-

Fail-Safe-Output
0 V at analog output (AO)
open contact (fail-safe relay)/ green LED off

optris PI 200 Specifications

General

Brand	optris
Model	PI 200
Category	Thermographic Cameras
Language	English
