Girard 8’ Manually Retractable Sun Awning
The OP15 Sun awning is a manually deployed 8’ sun awning designed to provide shade over the kitchen area. You will nd the
supplied manual awning crank arm in the exterior slide out bin of your OP15. To set up your awning:
1. Ensure you have a minimum of 8’ clearance from any nearby obstacles that may obstruct the awning before deploying it.
2. Insert the crank arm T-ng vercally into the receiver located on the underside of the awning on the right side.
3. Crank clockwise to extend the awning. Do NOT extend the awning to its maximum extension as this can damage the elbow
joint. See image 3. below for suggested angle to deploy to.
4. To retract the awning, use the manual crank arm in the same receiver as above and crank counter clockwise unl the awning is
fully retracted and the crank mechanism prevents further turning.
IMPORTANT! Awning may only be used in very light wind and rain condions. When periods of moderate rain and or
wind are expected the awning must be closed. Please ensure the awning is retracted at the rst sign of wind or rain
condions to prevent serious injury and damage. Damage caused by wind and rain is not covered under warranty.
Never leave the awning open and unaended.
Please ensure your awning is fully retracted before moving your OP15 for any reason. Damage caused by failure to comply with
this instrucon is not covered under warranty. Damaged caused by collisions with objects in the area in which the awning will
be deployed will not be covered under warranty. Do NOT over extend the awning. Ensure there is a good bend in the extension
arm at all mes.
SETTING UP YOUR OP15 AWNING
1 2 3a.
3b.
Rooftop A/C
The OP15 comes ed with a rooop Domec Penguin II 120v A/C
unit. We strongly recommend that you read the instrucon manual for
this appliance in full before use for full instrucons and maintenance
informaon. Failure to follow the instrucons may result in damage to
the appliance which will not be covered under warranty.
You must be connected to a source of 120v electricity via either shore
power or a generator to run the A/C unit as it will drain your baeries
very quickly via the invertor.
Use the le hand dial to select the fan or cooling fan strength and use
the right hand dial to select the temperature. Please keep all windows,
doors and skylights closed for maximum eciency when appliance is in
use.
