28
WINDOWS & DOOR
Window Screens
There are six windows solid-pane openable windows in the
OP15 as well as zip-vent windows in the tent material of the
roof. Each solid-pane window has two oponal screens in
addion to the standard clear window mode; a mesh insect
screen & an opaque curtain screen.
The black clasp located on the center of the lower silver
screen bar is used to lock the screens in place.
1.Slide the lower silver screen bar up to reveal the curtain
screen.
2.As shown in the image, press the boom of the clasp to
lever the hook up
3.Hook the clasp over the lip of the top silver screen bar.
4.To release, press the clasp again and release the hook.
5. Slide the top silver screen bar down to reveal the mesh insect screen & lock in the same way.
The solid-pane windows are openable, hinged along the top edge. There are locking latches on each window*. These latches also
allow you to open the window to a ‘vent mode’ by latching on the secondary latch. Remember to close fully for storage.
Turn latches through 90° to clock/unlock. To open, push the
window outwards from the boom. Gas struts will hold the
window in place at the point they are opened to.
To close the window, push it all the way open unl you hear an
audible ‘click’. This will release the gas strut and allow you to
close the window.
*Note some of the latches may have a release buon in the center
of the latch that needs to be pressed in order to turn the latch.
1
2
3 5
