Oracle Database Appliance X7-2M Service Manual

Servicing Oracle Database Appliance Version 1 CRUs
Note - All of the CRUs on the storage shelf and the storage expansion shelf can be replaced
while the power is on. See “Oracle Database Appliance X3-2/X4-2/X5-2 and X6-2-HA/
X7-2-HA Storage Shelf Hot-Pluggable Components” on page 78 for storage shelf component
replacement procedures.
Note - The links in the following table take you to instructions outside of the Oracle Database
Appliance library to the Sun Server X3-2, Sun Server X4-2, and Oracle Server X5-2
documentation libraries. Use your browser's Back button to return to the Oracle Database
Appliance library.
Oracle Database Appliance X3-2 Oracle Database Appliance X4-2 Oracle Database Appliance X5-2
CRU Locations CRU Locations CRU List
Servicing DIMMs (CRU) Servicing DIMMs (CRU) Servicing DIMMs (CRU)
Servicing PCIe Risers (CRU) Servicing PCIe Risers (CRU) Servicing PCIe Risers (CRU)
Servicing PCIe Cards (CRU) Servicing PCIe Cards (CRU) Servicing PCIe Cards (CRU)
Servicing a DVD Drive (CRU) Servicing a DVD Drive (CRU) An optional DVD drive for this
system is considered a FRU.
See “Servicing Oracle Database
Appliance X3-2/X4-2/X5-2
FRUs” on page 118.
This system does not include an
internal USB flash drive.
Servicing the Internal USB Flash
Drives (CRU)
Note - A factory installed flash drive
is reserved for future use.
Servicing the Internal USB Flash
Drives (CRU)
Note - A factory installed flash drive
is reserved for future use.
Servicing the Battery (CRU) Servicing the Battery (CRU) Servicing the Battery (CRU)
Servicing Oracle Database Appliance Version 1 CRUs
This section describes how to service customer-replaceable units (CRUs) for Oracle Database
Appliance Version 1. If you have Oracle Database Appliance X6-2 series, go to “Servicing
Oracle Database Appliance X6-2 Series CRUs” on page 102. If you have Oracle Database
Appliance X3-2, Oracle Database Appliance X4-2, or Oracle Database Appliance X5-2, go to
“Servicing Oracle Database Appliance X3-2/X4-2/X5-2 CRUs” on page 103.
This section includes information on how to service the following Oracle Database Appliance
Version 1 CRUs:
■
“Server Node CRU Component Locations” on page 166
■
“Servicing Memory Modules (DIMMs) (CRU)” on page 168
■
“Servicing PCIe Risers (CRU)” on page 177
104 Oracle Database Appliance Service Manual • November 2017
