Servicing CRUs That Require Server Node Power Off
Callout Description
1 DDR3 Memory DIMMs (12)
2 PCIe Cards Mounted on PCIe Riser
3 PCIe Riser
4 Internal HBA PCIe Card
5 Battery
Appendix A • Servicing the Oracle Database Appliance Version 1 167
