Servicing Hot-Pluggable Components
118 Oracle Database Appliance Service Manual • June 2017
Note - After a physical insertion or removal action of a storage component (such as a disk or
SAS cable), you should wait before performing the next action to allow the system software to
fully process the event. This could take up to 3 minutes to complete.
Note - For the Oracle Database Appliance Version 1, you must run the oakcli add disk -
local command after replacing a failed disk. Refer to the Administration and Reference Guide
for details.
Servicing Storage Drives and Boot Drives (CRU)
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
Oracle Database Appliance Version 1 has 24 storage drives, located in the front of the chassis,
and each server node has 2 boot drives, located in the rear. All storage drives and boot drives
are hot-pluggable.
See “Storage and Boot Drive Status Indicators” on page 41 for specific information about drive
status LEDs.
This section includes:
■
“Storage and Boot Drive Locations” on page 118
■
“Remove a Storage Drive” on page 120
■
“Install Storage Drive” on page 121
■
“Remove a Boot Drive” on page 122
■
“Install a Boot Drive” on page 124
Storage and Boot Drive Locations
Appliance storage drives. Appliance storage drives are installed at the front of Oracle
Database Appliance Version 1. Drive numbering is listed on the drive label on the right side of
the appliance [1].
