Remove Disk Midplane Module
AppendixA • Servicing the Oracle Database Appliance Version 1 177
This section includes:
■
“Remove Disk Midplane Module” on page 177
■
“Install Disk Midplane Module” on page 180
Remove Disk Midplane Module
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing the disk midplane module from Oracle Database Appliance
Version 1.
1.
Prepare the system for service.
a.
Power off the system.
See “Shutting Down a Server Node and Powering Off the System” on page 109.
b.
Disconnect the power cords from the system.
c.
If the system is installed in a rack, remove it.
See the Oracle Database Appliance Owner's Guide for information on racking the system
chassis.
d.
Remove both power supplies from the system.
See “Remove a Power Supply” on page 129.
e.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention
Measures” on page 112.
2.
Remove all of the front storage drives.
See “Remove a Storage Drive” on page 120.
3.
Remove both server nodes from the system.
See “Removing Server Nodes From the System Chassis” on page 113.
4.
Remove the middle section of the system top cover.
See “Removing the Middle Section of the System Top Cover” on page 115.
