Oracle Database Appliance X7-2S/X7-2M Status Indicators
Oracle Database Appliance X7-2S/X7-2M Status Indicators
The following topics describe the Oracle Database Appliance X7-2S/X7-2M status indicators.
They include controls and indicators on the server front and back panels, storage drives, and
power supplies.
■
“Oracle Database Appliance X7-2S/X7-2M Server Status Indicators” on page 12
Oracle Database Appliance X7-2S/X7-2M Server
Status Indicators
These topics describe Oracle Database Appliance X7-2S/X7-2M server status indicators
(LEDs).
Server Front Panel Status Indicators
The Oracle Database Appliance X7-2S/X7-2M server front panel includes indicators for the
system and storage drives.
12 Oracle Database Appliance Service Manual • November 2017
