FIGURE A–4 Cabling a StorEdge A3500 Storage System: An Example, Part 1
Node A
Differential SCSI terminators
Controller A
Controller B
FIGURE A–5 Cabling a StorEdge A3500 Storage System: An Example, Part 2
Node A
Node B
Sun StorEdge A3500 Cabling Diagrams
