Oracle Solaris Cluster 3.3 User Manual

Sun StorEdge A3500 Cabling Diagrams
Installing a Sun StorEdge A3500 Storage System
For more sample congurations, see the Sun StorEdge A3500/A3500FC Hardware
Conguration Guide.
For the procedure about how to install the cables, see the Sun StorEdge A3500/A3500FC
Controller Module Guide.
Adding a Sun StorEdge A3500 Storage System
Connect the dierential SCSI cable between the node and the controller module, as shown in
Figure A–4. Ensure that the entire SCSI bus length to each storage array is less than 25 m. This
measurement includes the cables to both nodes, as well as the bus length that is internal to each
storage array, node, and host adapter.
FIGURE A–3 Installing a StorEdge A3500 Storage System: An Example
Node A
Node B
Sun StorEdge A3500 Cabling Diagrams
Appendix A • Cabling Diagrams 51
