Oracle Solaris Cluster 3.3 User Manual

Figure A–2 illustrates how to cable the storage array in a daisy-chain conguration. If you place
two storage arrays on a SCSI chain, ensure that each storage array's ID dial is set to a unique
number.
FIGURE A–1 Installing a Storage Array With One Pair
Node A
Node B
FIGURE A–2 Storage Array With Two Pairs and Daisy Chaining
Node A
Node B
Sun StorEdge A1000 and Netra st A1000 Cabling Diagrams
Oracle Solaris Cluster 3.3 With StorEdge A1000 Array, Netra st A1000 Array, or StorEdge A3500 System Manual
• May 2011, Revision A
50
