Manual for Orange’s Tire Pressure Monitoring Systems, TPMS
3/14 www.orange-electronic.com
Orange Electronic Co., Ltd
Specifications of Orange TPMS
1. SENSOR AND TRANSMITTER SPECIFICATIONS
Battery life More than 8 years, nominal.
Storage temperature -40
o
C to 125
o
C
Operating temperature -30
o
C to 105
o
C
Operating humidity 95%
Operating frequency 433MHz
Pressure monitoring range 0~81 psi for 4 tires of passenger cars (or 96
psia)
Pressure reading accuracy At Normal condition
± 1psi at normal pressure range
Temperature reading accuracy
± 4
o
C in normal environmental condition
Transmission power Max 5 dBm
Battery 3.6V
Sensor weight 35gm
2. RECEIVER SPECIFICATINS
Operating voltage 12V DC
Operating current 200mA
Monitored temperature range -40
o
C to 125
o
C
Operating temperature -40
o
C to 85
o
C
The System Installation
There are two parts of system installation
1. Setting up the display unit in the vehicle
2. Installing the transmitter unit sensor in each tire.
We strongly suggest installing the display unit first, and then install the tire transmitters.
Accessories for Orange’s Tire Pressure Monitoring System
NO. Accessory Name Quanity
A Wireless Receiver and Display Unit 1
B Holder for Display in Air Conditioner Unit 2
C Power Connection for Cigarette Lighter 1
D Wireless Transmitter Sensor (Remote Sensing
Module)
4
E Tire Valves 4
F Screw for Tire Valves (Nylok screw) 4
G Manual 1
