TECHNICAL MANUAL BLUE PAPER GAIN · HYDRO 202130 | ORBEA ORBEA | 31
EN
COD. DESCRIPTION CORRECTIVE MEASURE
11 COMMUNICATION FAULT LOST FRAME JOB Remote control communication error. Check the remote connector.
If the problem persists, contact your ebike dealer.
12 &4+8'4'44148)70&'481.6#)' Battery pack voltage too low. Charge the battery pack.
13 &4+8'4'441418'46'/2'4#674' The ebike is outside of the permissible temperature range. Turn off
the ebike and allow the drive unit to either cool down or heat up to the
permissible temperature. Restart the system. If the problem persists,
contact your ebike dealer.
14 &4+8'4'441418'4%744'06 Current supplied by the battery pack is too high. Reduce the demand.
If the system locks, restart the ebike system. If the problem persists,
contact your ebike dealer.
15 &4+8'4'44148&&70&'481.6#)' Battery pack voltage too low. Charge the battery pack.
16 PHASE I SCG Check the motor wire connection and restart the ebike system.
If the problem persists, contact your ebike dealer.
17 PHASE II SCG Check the motor wire connection and restart the ebike system.
If the problem persists, contact your ebike dealer.
18 PHASE III SCG Check the motor wire connection and restart the ebike system.
If the problem persists, contact your ebike dealer.
19 PHASE I SCS Check the motor wire connection and restart the ebike system.
If the problem persists, contact your ebike dealer.
20 PHASE II SCS Check the motor wire connection and restart the ebike system.
If the problem persists, contact your ebike dealer.
21 PHASE III SCS Check the motor wire connection and restart the ebike system.
If the problem persists, contact your ebike dealer.
22 PHASE I CONNECTION ERROR Check the motor wire connection and restart the ebike system.
If the problem persists, contact your ebike dealer.
23 PHASE II CONNECTION ERROR Check the motor wire connection and restart the ebike system.
If the problem persists, contact your ebike dealer.
24 PHASE III CONNECTION ERROR Check the motor wire connection and restart the ebike system.
If the problem persists, contact your ebike dealer.
25 COMPONENT PROTECTOR Check the motor wire connection and restart the ebike system.
If the problem persists, contact your ebike dealer.
COD. DESCRIPTION CORRECTIVE MEASURE
26 08/'44142#4#/561&'#.'4 Take the ebike to your dealer to set to the default system parameters.
27 08/+'44145#8'&'44145.156 Error in the error database system. Restart the ebike system.
If the problem persists, contact your ebike dealer.
28 '/0'4414+/2155+$.'5#8''44145 Error database system full. Restart the ebike system. If the problem
persists, contact your ebike dealer.
29 $#66'4;81.6#)'5'0514(#7.6 Battery pack sensor damaged. Restart the ebike system. If the problem
persists, contact your ebike dealer.
30 18'4%744'062416'%6+10 Current supplied by the battery pack is too high. Reduce the demand.
If the system locks, restart the ebike system. If the problem persists,
contact your ebike dealer.
31 2'#-18'4%744'062416'%6+10 Current supplied by the battery pack is too high. Reduce the demand.
If the system locks, restart the ebike system. If the problem persists,
contact your ebike dealer.
32 COMM FATAL ERROR Fatal error. Restart the ebike system. If the problem persists, contact your
ebike dealer.
33 CURRENT NO SPEED .QEMGFOQVQT%JGEMVJCV9#.-OQFGYQTMUƂPG+HVJGRTQDNGORGTUKUVU
contact your ebike dealer.
34 #%%81.6#)''4414 Power supply problem in the HMI bus. Contact your ebike dealer.
35 5'051458'4414 Power supply problem in sensors. Check the wires on the pedaling sensor
(PAS sensor) and motor sensor. If the problem persists, contact your ebike
dealer.
36 .+)*658'4414 Power output failure in the lights line. Check the wiring and accessory
connected to the light line. If the error persists, disconnect the accessory
and check again. If the error is corrected, the accessory exceeds
VJGQWVRWVURGEKƂECVKQPU+HVJGGTTQTRGTUKUVUEQPVCEVVJGCEEGUUQT[
manufacturer.
CONSULT THE USER APP MANUAL
Download the complete User App manual for a full guide on all features and functions of the ebikemotion® User App at:
www.ebikemotion.com

Orbea GAIN D40 Specifications

General

Fork	Carbon
Motor	Ebikemotion X35
Crankset	Shimano Tiagra 4700 34x50t
Chain	KMC X10
Weight	13.5 kg
Frame Material	Aluminum
Drivetrain	Shimano Tiagra
Tires	Vittoria Zaffiro 700x30c
Stem	OC1 31.8mm
Handlebar	Orbea OC-II
Rear Derailleur	Shimano Tiagra
Shifters	Shimano Tiagra
Wheels	Ready GR
Seatpost	Orbea OC-II
Saddle	Selle Royal
Display	Ebikemotion X35
Charger	Ebikemotion X35
